XCMG Construction Wheel Loader ZL50GN 5 Ton For Digging Earth And Moving Earth
Wheel Loader is a kind of earthwork construction machinery widely used in highway, railway, construction, hydropower, port, mine and other construction projects. It is mainly used for shoveling bulk materials such as soil, sand, lime, coal, etc. It can also be used for slight shoveling and excavation of ores, hard soil, etc. Different auxiliary working devices can also be used for bulldozing, lifting and loading and unloading of other materials such as wood.
XCMG wheel loader ZL50GN is the most popular model of China 5t wheel loader,Now ZL50GN is upgrading to new model ZL50GV equipped with EURO III engine with electric injector, new model will have high performance.
Advantage:
1. Fast operation and high efficiency
2. Good maneuverability
3. Simple and portable operation
4. High torque and high efficiency drive chain features reasonable matching.
5. The 160kN traction force and ≥3.5m high dumping capacity handle the severe conditions with ease.
6. This engine meets the instant overload demand during operations and sufficiently provides the power required for heavy-load operations.
7. The air-assisted hydraulic four-wheel caliper brakes feature stable braking and high safety and reliability.
8. The easy and convenient daily maintenance ensure that the machine is under the best ready status at all times.
Main Parameter:
| Description | Unit | Parameter value |
| Rated operating load | kg | 5000 |
| Bucket capacity | m³ | 2.5~4.5 |
| Machine weight | kg | 17500±300 |
| Dump clearance at maximum lift | mm | 3100~3780 |
| Reach at maximum lift | mm | 1100~1220 |
| Wheel base | mm | 3300 |
| Tread | mm | 2250 |
| Max.breakout force | kN | 175±5 |
| Max.horse power | kN | 160±5 |
| Hydraulic cycle time-raise | s | ≤6 |
| Total hydraulic cycle time | s | ≤10.5 |
| Min. turning radius over tyres | mm | 5925±50 |
| Articulation angle | ° | 38 |
| Gradeability | ° | 30 |
| Tyre size | | 23.5-25-16PR |
| Overall machine dimension L×W×H | mm | 8225×3016×3515 |
| Model | | WD10G220E21 |
| Rated Power | kW | 162 |
| Travel Speed | Ⅰ-gear(F/R) | km/h | 13/17 |
| Ⅱ-gear(F) | km/h | 41 |
8 tons of wheel loaders can be equipped with the above tools:
with rock bucket/ with big bucket / with wood grab/ with tube grab / with pallet fork /with fork/ with snow plough / with side-dump bucket /with quick hitch /with lift/with high dump bucket/with long boom/with wood grapple/
Packaging & Shipping
We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.
