Large Capacity Liquid Tanker Truck 15000L Water Tanker Lorry 266hp Engine
Sinotruk Howo 4x2 Tank Capacity 15000L Water Tank Sprinkler Truck 266hp Engine LHD&RHD
Introduction for Howo 15000L water sprinkler truck:
The main functions include front spraying, rear spraying, high-pressure water gun (remote spraying), self-draining, and self-absorbent water. The spraying system can be installed according to actual needs to achieve garden vegetation pesticide spraying and emergency epidemic prevention. The water truck produced by Sinotruk has reasonable design, beautiful appearance, and large liquid carrying capacity.
Features of Howo 15000L water sprinkler truck:
1, Sinotruk WD615.62, WD615.87, WD615.69, WD615.47, 266hp, 290hp, 336hp,371hp are optional.
2, Volume of tank: 15000L-20000L
3, Low oil consumption with good economic.
4, Pump: Chinese famous brand pump
5, Self suction, self discharge function, front flushes sprinkles, side spurts, post positioned work table.
6, High-pressured Sprinkler, spraying of water to be possible to adjust columnar and the fog shape.
7, Optional fire pump and fire-fighting accessories.
8, Especially suitable for the municipal administration environmental sanitation department, the large-scale industry and mining enterprise.
9, BV ISO CCC approved, accept customes' OEM customized.
Features of the water tanker:
1, Applied carbon steel sheet Q235-A; Stainless steel; Aluminium alloy.
2, Applied the famous pump.
3, The main parts implements automatic welding.
4, Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.
5, Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.
Technical specification of Howo 15000L water sprinkler truck:
| Cabin | HW 76 cab, with one bed and air condition, 70°hydraulically tillable to the front as attached photo for ref. |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8950×2496×3348 |
| Wheel base (mm) | 4600 |
| Wheel track (front/rear) (mm) | 2022/1830 |
| Approach/Departure angle(°) | 16/14 |
| Weight in KGS | Tare Weight | 7420 |
| payload | 15000KGS |
| Front axles loading capacity | 1x7000 |
| Rear axles loading capacity | 1x16000 |
| Max. driving speed(km/h) | 90 |
| Engine | Brand | Sinotruk |
| Model | WD615.62 |
| Type | 4-stroke direct injection , 6-cylinder in-line, turbo-charging and inter-cooling |
| Horse Power(HP) | 266 HP |
| Emission standard | Euro-II |
| Gearbox | 10 Forwards gear & 2 reverse gear |
| Steering | power steering ZF8098 from Germany |
| Tire | 295/80R22.5 tubeless tire, 7 pieces including one spare tire |
| Tank specification | 15,000 liters, tank thickness is 5 mm, seal is 6 mm
Equipped with front(rear,side)sprinkler(sprinkling width>14m )
Equipped with rear working platform with water cannon (range>28m)
Equipped with pump(suction lift>6m)
Equipped with fire valve,water valve,and filter gauze |
| Production cycle | 30 days |
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
FAQ
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok .But we need take apart the truck. You should reinstall in your country.
Q: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q: I want to be your agent in my country , is that ok?
A: It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q: I want the front two types are bias tyre and the rear 9 tyres are radial tyres, is it ok?
A: We can make the types as your requirement to suit your country's need.
