White Color 6x4 Heavy Duty Dump Truck 5.6m Dumper Box for Loading Stone and Sand
Technical specification of White Color 6x4 Heavy Duty Dump Truck
| Model | ZZ3257N3847D1 |
| Drive form | 6X4 |
| Wheelbase | 3825+1350mm |
| Body length | 8.545m |
| Body width | 2.496m |
| Body height | 3.28m |
| Wheelbase | F:2022 , R:1830/1830mm |
| Vehicle weight | 12.44t |
| Rated load | 12.43t |
| Total quality | 25t |
| Tonnage level | 30ton |
| Approach angle | 19 |
| Departure angle | 23 |
| Origin | Jinan |
| engine | |
| Engine model | WD615.69 |
| Number of cylinders | 6 |
| Fuel type | Diesel |
| Displacement | 9.726L |
| Emission Standards | Euro III |
| Maximum horsepower | 336hp |
| Maximum output power | 249kW,213kW,276kW |
| Torque | 1490N·m |
| Maximum torque speed | 1200-1500rpm, |
| Rated speed | 1900rpm |
| Engine form | Inline six-cylinder, water-cooled, four-stroke, supercharged and intercooled, high-pressure common rail |
| Cargo box parameters | |
| Cargo box length | 5.6m |
| Cargo box width | 2.3m |
| Cargo box height | 1.1m |
| Cargo box form | Rear dump |
| Gearbox | |
| Gearbox | HW19710, |
| Forward gear: | 10 |
| Number of reverse gears: | 2 |
| Tire | |
| Tire specifications: | 11.00-20 11.00R20 12.00-20 12.00R20 |
| Number of tires: | 10pcs |
| tank | |
| Fuel tank capacity: | 400L |
| Chassis | |
| Rear axle description: | AC16 |
| Rear axle allowable load: | 16000kg,18000kg |
| Rear axle speed ratio: | 5.45, |
| Number of springs: | 10/12,9/12 |
Packing & Delivery:
Nude package.
This model truck crane shipped by roro or bulk ship.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-sale service:
Spare Parts When You Need Them
We have thousands of spare parts centers across five continents that stock almost 1 billion specialist spare parts. We promise that spare parts will be delivered within 72 hours.
After-market Worry-free Service
We are committed to providing after-market services, including rentals, second-hand vehicle evaluations, trade-ins, overhauls, and recycling. We always stick to our responsibility and mission of handling your concerns as best we can.
Quality warranty
We grant our clients a fourteen-month or 2000-hours warranty for any machine purchased from us.
