SCEC 3 Axles Flatbed Semi Trailer Max Loading 50 - 60ton With Front Side Plate
Features of SCEC 3 Axles Flatbed Semi Trailer Max.Loading 50-60ton Transport Bulk Commodity and Container
1. Strong bearing capacity
2. Reinforced design of the frame, which adopts the reinforced design, has strong bearing capacity and does not undergo permanent deformation.
3. Reliable quality and wide range of applications, suitable for a variety of machinery and equipment transportation, a variety of steel transportation.
Stainless steel
4. The vehicle adopts computer-aided design software to optimize and design flexibly and diversely. The frame bearing surface is designed according to user requirements to meet the transportation of various special goods.
5. High transportation efficiency and reliable quality. Its frame is stepped and the longitudinal beam section is I-shaped. It has the characteristics of high rigidity and high strength.
SCEC 3 Axles Flatbed Semi Trailer Max.Loading 50-60ton Transport Bulk Commodity and Container technical specification
| SCEC 3 Axles Flatbed Semi Trailer Max.Loading 50-60ton |
| Tare weight | About 7500kg |
| Size | 13500mm×2500mm×1550mm |
| Payload | 50-60 Ton |
| Chassis | Main beam: Top flange 14mm,width140mm;Middle Flange 8mm height 500mm;bottom flange16mm,width 140mm |
| Side beam: 16# channel steel(Q235) |
| Cross beam: 10# channel steel(Q235) |
| Floor | 5mm Flat Plate |
| Axle | 3 axle 13T ( Original FUWA brand ) |
| Landing gear | Two-speed, manual operating,heavy duty landing gear 28T |
| Suspension | Mechanical suspension |
| Leaf spring | Leaf spring 6sets , 10pcs,90×13 mm |
| Tire | 12.00R20, 12pcs |
| Wheel rim | 9.0-22.5 , 12pcs |
| Kingpin | 3.5” bolt-in king pin |
| Twist lock | 8 pcs and optional |
| Braking system | WABCO RE6 relay valve ; T30/30 spring brake chamber;40L air tanks |
| Lights | LED 8 side lights and 2 rear lights 2 width lamp |
| Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
| Accessories | One tool box;one spare tire carrier;one crank;one shaft head wrench;four side light;two rear light |
Packaging & Shipping:
We transport the semi trailers by bulk or container. Our factory possesses long-term cooperation with ship agency which can provide you lowest shipping fee.
FAQ:
What’s The Guarantee Period On Our Products ?
- All Products We Export Has 1 Year Guarantee Period, And For The Beam Is Lifetime Promise. As Exporting Experience
For Years, All Products From Our Factory Can Meet The Exporting Country’s Standards On Vehicles, All Vehicles Will Be
Built Upon The Related Countries’ Road Condition, And Our Sales Manager Will Provide Customer The Best Suggestions Before Placing The Order. If Some Easy Weary Small Parts, We Can Offer Free In 6 Months.
If Customized Service Provided ?
- Yes, Please Contact Our Sales Manger, We Can Offer Customized Service On Vehicle Design / Painting, Etc.
- Oem Available
If Our Vehicle/Trailer Can Couple With Your Tractor Head ?
- 90% Of The Truck In The Market Can Coupling With Our Vehicle, As Howo, Shacman, Beiben, Volve...
- If Other Brand Truck Head, Please Inform Our Sales Manager Before Order Placing, We Need To Adjust The Height And Overhang To Couple With The Using Truck.
Whats The Time For Delivery & Arrival ?
- If Standard Model We Have In Stock Can Ship It Out Within 10 Days After Payment.
- If It Belongs To Customize Series, Ordinary Cases In 15 Days Can Be Finished For Shipment.
- For Asian Countries, Ship Can Be Reached In 1-2 Weeks, If For African & Mid East & European Countries,
25 Workdays Will Be Achieved.
