12t ANFO Truck BCLH-12 Digital On-Site Mixed and Charging Granular ANFO Truck Ammonium Explosive Truck for Mining Project
Introduction of BCLH-12 Digital On-Site Mixed and Charging Granular ANFO Truck Ammonium Explosive Truck
The ANFO truck is mainly composed of chassis, power output system, dry material tank, fuel tank, conveying screw, electrical equipment and so on. It is mainly used to fill anhydrous blastholes with ammonium frost in large and medium-sized open-pit mines such as metallurgy, coal, chemical industry, and building materials.
Before work, load diesel and porous granular ammonium nitrate in the ground station.
The charging vehicle drove to the operation site, started the power take-off, aligned the feeding screw to the blast hole, entered the charge amount of the blast hole on the counter, pressed the start button, the porous granular nitric acid was sent to the oblique spiral through the bottom spiral of the tank, From the oblique spiral to the side spiral agitator, the diesel pump also pumps the diesel into the side spiral agitator in proportion to mix, and the uniformly mixed explosive is then transported into the gun hole by the side spiral. When the amount of explosive in this blasthole reaches a predetermined amount, the control device issues a command to stop and shift to the next blasthole to start charging.
The delivery efficiency is 200kg / min --- 450kg / min;
Measurement error ≤2%
At present, six specifications such as 4T, 6T, 8T, 15T and 25T are available.
Technical specification of BCLH-12 Digital On-Site Mixed and Charging Granular ANFO Truck Ammonium Explosive Truck
| Chassis |
| Brand&Model | SINOTRUK HOWO ZZ1257N3647A |
| Engine | Model | WD615.47 |
| Manufacture | Sinotruk |
| Type | Diesel, water-cooled, four strokes, 6 cylinders, in line with water cooling, turbo charged, And inter-cooling & direct injection. |
| Engine capacity | 371hp |
| Emission standard | Euro II |
| Drive wheel formulation | 6x4 |
| Wheelbase | 1800+3600 |
| Cabin | HW70, no sleeper |
| Transmission | HW19710 transmission + HW70 flange type power take-off |
| Front axle | HF9 |
| Loading: 9000kg |
| Chimney system | Smoke evacuation (with fire lid) |
| Tires | 12.00R20 /steel tires/, 10+1 pcs |
| Fire extinguisher | one pieces for machine, two pieces for equipment |
| Warnings | Hazardous freight warnings according to Mongolian law and regularity must be sticked /4 sides of the machine / |
| Amber light | On the cabin-1 pieces Equipment -1 pieces |
| Other directions | PTO option: /front and bottom protection/ · Speed limiter device, speed limit 60 km/hour |
| Brake system | ABS (4S / 4M) |
| Fuel tank | Min-200 L / aluminum alloy fuel tank/ |
| Others | / The vehicle meets the conditions of adapting to the working conditions of the plateau and cold regions./ |
| Steering wheel | Left HT457 rear dual drive axle (drum) |
| Axle’s loading capacity | kg | 9000 / 16000 |
| Loading | kg | 25000 |
| Over all weight | kg | 31000 |
| Dimension of the machine and equipment | mm | 9105×2480×3470 |
| Mixing charger device of material | Stainless steel |
| Amount of explosives | kg | 12000 | 13.5m³/12ton |
| Wall thickness of AN tank | mm | 4-6 |
| Borehole charging depth | м | 20-30 | |
| Borehole charging speed | kg/min | 200-450 | Adjustable |
| Measurement error, | % | ± 2 | |
| Borehole charging diameter | мм | 165-250 | Adjustable |
| Porous ammonia container /equipment/ | kg | 12000 | |
| Diesel fuel tank volume, /equipment/ | tn | 0.90m³/0.74ton | |
| Location of tank loading | Pour over the tank loading or site screw system |
Technical service commitment:
1. The quality of the ANFO truck meets the requirements of GB17583.
2. When the truck is used, Party B is responsible for training the user on safety, technology, equipment maintenance and repair, and is responsible for equipment commissioning and guiding trial production.
3. When the equipment is delivered, provide the operation, use and maintenance instructions of the listed pharmaceutical part, relevant information of the automobile chassis and process technical information.
