SCEC Special Purpose Truck 12ton Hook-Arm Garbage Truck Detachable Garbage Truck 266hp Euro III
Brief introduction of SCEC Special Purpose Truck 12ton Hook-Arm Garbage Truck Detachable Garbage Truck
Pull-arm garbage trucks are called detachable garbage trucks or hook-arm garbage trucks. The chassis uses HOWO Euro III 266 horsepower chassis, the pull arm is 0VO (Ouweiwo) 12 tons sleeve arm, and the domestic famous brand hydraulic double cylinder ( Cylinder bore 0140), three (four) combined electrical control multi-way valve. Domestic high-pressure pump, remote control + manual operation, reserved hydraulic quick connector interface of the trash bin, equipped with 10-15 cubic bulk multi-functional bulk trash bin (hydraulic wingspan upper cover, hydraulic locking sealed rear door) or 8-10 cubic conjoint compression Type trash can (mobile garbage station).
Parameters of SCEC Special Purpose Truck 12ton Hook-Arm Garbage Truck Detachable Garbage Truck
| Chassis Model | ZZ1167M4611W |
| Cabin | HW76 Long Cabin, with two seats and one bed, with Air Conditioner and electric window. |
| Engine | Model | WD615.62 |
| Horse Power (Hp/rpm) | 266/2200, Euro II Emission Standard |
| Max.Toruqe(Nm/rpm) | 1100/1100-1600 |
| Displacement L | 9.726 |
| Type | 6-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke direct injection diesel engine |
| Transmission | HW19710, 10 speeds forward and 2 speeds reverse. |
| Front Axle | HF7, Steering with double T-cross section beam, Loading Capacity: 9,000kgs |
| Driving Axle | ST16, Pressed axle housing, central reduction with hub reduction, with differential locks between wheels and axles. ratio: 4.8. Option: 4.42 |
| Suspension | Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer |
| Steering System | ZF8118, Hydraulic steering with power assistance |
| Brake System | Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake |
| Tire | 12.00R20 |
| Fuel Tank Capacity (L) | 300L Diesel Tank |
| Kurb Weight (kg) | 9,200 |
| Loading Capacity (kg) | 10,800 |
| Gross Vehicle Weight (kg) | 20,000 |
| Overall Dimension(L*W*H)(mm) | 6000×2300×1500 |
| Tank Capacity(L) | 12ton |
| Tank Material | Carbon Steel |
| Nos of Compartment | 1 |
| Wheelbase(mm) | 4600 |
| Max. Speed (km/h) | 75 |
Packing and Delivery:
Packing: waxing on the appearance of the trucks or nude packing.
Delievery: 20 days after receiving deposit
Payment term: 30% deposit, 70% balance payment delivery after receipt.
Shipping: usually by RORO or BULK vessel,can also by 40FR container,some small trucks can be fitted into 20GP or 40HQ
container.Will give you the best case for transportation.
